Savema TTO
The high performance, cost-effective SAVEMA Thermal Transfer Over printers (TTOs) are versatile enough for printing fixed and variable text, data, and graphics. It is ideal for reproducing bar codes, real-time, sell-by dates, batch numbers, prices, source codes and much more. Versatile brackets can be easily integrated into machines such as vertical and horizontal form-fill-seal systems, primary labelers, thermoformers, and overwrapping equipment. The units are suitable for all continuous applications within the food, pharmaceutical cosmetics, and automobile spare parts industries and have the capability to code all kinds of 1D/2D barcodes and Datamatrix codes
Models
- Continuous mode operation — ideal for high-speed form-fill-seal and wrapping lines
- 4.3" touch panel colour control screen
- 300 dpi (12 dots/mm) print resolution — horizontal and vertical
- 600 metre ribbon capacity
- 90°, 180° and 270° template rotation
- 5,000 template storage capacity in control screen memory
- Programming: Real Date/Time, Text, 1D/2D Barcodes, GS-1 Barcodes, Logo, Counter (Serial No.), Shift Code, Shape, Currency, Database Support, Table Creation
- 1D Barcodes: EAN-13, EAN-8, CODE 128, CODE 39, CODABAR, ITF 2of5, ITF 14, UPCA, UPC-E
- 2D Barcodes: Datamatrix, QR Code, PDF417, Aztec
- GS-1 Barcodes: GS1-128, GS1-Datamatrix, GS1-Databar
- Communication: RS-232, Ethernet, USB
- PC Programme: Sayasis S20 (All Features Free)
- Power Supply: 100/240V 50/60 Hz
| Print Area | 32mm x 125mm |
|---|---|
| Print Speed | 10 - 550 mm/sec |
| Production | 500 prints/min |
| Ribbon Widths & Lengths | 25mm, 35mm (0,9" - 1,4") & 600 meters (656 yards) loaded ribbon |
| Power Supply | 100-240V 50-60 Hz |
| Air Supply (Bar) | Min. 1 bar - Max. 5 bar |
| Input/Outputs | Print Signal/Fault Signal, Busy Signal |
| Output Messages | Missing Print Error, Encoder Error, Update Error, Contact Error, Ribbon Break / Not Found Error, Remaining Ribbon Quantity, Number of Printed Templates, Number of Prints per Minute |
| Connection Types | Relay (NPN, PNP) - Photocell (NPN, PNP) |
| Communications | RS-232, Ethernet, USB |
| Ribbon Save Modes | Vertical Ribbon Save Mode |
| Advanced Control | 4.3" Touch Screen Control, Template Changing while Running, Contrast, Print Delay, Template-Specific Adjustment, Internal Contact Signal, Multi-print Contact Signal, Template Shifting, Template Rotation |
| Operator Interface | 4.3" 272x480 pixels resolution, Full-color dispaly, Password protection on menus, Multi-language(18) support |
| Weight (Printer) | 5,1 Kg. |
| Dimensions | 175mm H x 190mm W x 197mm D |
- Continuous mode operation — ideal for high-speed form-fill-seal and wrapping lines
- 7" touch panel colour control screen
- 300 dpi (12 dots/mm) print resolution — horizontal and vertical
- 1,000 metre ribbon capacity
- 90°, 180° and 270° template rotation
- 5,000 template storage capacity in control screen memory
- 1D Barcodes: EAN-13, EAN-8, CODE 128, CODE 39, CODABAR, ITF 2of5, ITF 14, UPCA, UPC-E
| Print Area | 32mm x 125mm (Standard), 32mm x 500mm (Optional) |
|---|---|
| Print Speed | 10 - 800 mm/sec |
| Production | 500 prints/min |
| Ribbon Widths & Lengths | 22mm, 35mm (0,9" - 1,4") & 1.000 meters (1.093 yards) loaded ribbon |
| Power Supply | 100-240V 50-60 Hz |
| Air Supply | Min. 1 bar - Max. 5 bar |
| Input/Outputs | Print Signal/Fault Signal, Busy Signal |
| Output Messages | Missing Print Error, Encode Error, Update Error, Contact Error, Ribbon Break / Not Found Error, Remaining Ribbon Quantity, Number of Printed Templates, Number of Prints per Minute |
| Connection Types | Relay (NPN, PNP) - Photocell (NPN, PNP) |
| Communications | RS-232, Ethernet, USB |
| Ribbon Save Modes | Vertical Ribbon Save Mode |
| Advanced Control | 7" Touch Screen Control, Template Changing while Running, Contrast, Print Delay, Template-Specific Adjustment, Internal Contact Signal, Multi-print Contact Signal, Template Shifting, Template Rotation |
| Operator Interface | 7" 800x480 Pixels Resolution, Full-color display, Password protection on menus, Multi-language(18) support |
| Weight (Printer) | 8,9 Kg. |
| Dimensions | 180mm H x 265mm W x 237mm D |
- Intermittent mode operation — no air requirement, magnetic drive
- Robust mechanical design requires no maintenance
- 4.3" touch panel colour control screen
- 300 dpi (12 dots/mm) print resolution — horizontal and vertical
- 600 metre ribbon capacity
- 90°, 180° and 270° template rotation
- 5,000 template storage capacity in control screen memory
| Print Area | 32mm x 40mm |
|---|---|
| Print Speed | 50 - 300 mm/sec |
| Production | 100 prints/min |
| Ribbon Widths & Length | 22mm, 35mm (0,9" - 1,4") |
| Power Supply | 100/240V 50/60 Hz |
| Air Supply (Bar) | Magnetic / Don't Need Air |
| Input/Outputs | Print signal / Fault signal, Busy signal |
| Output Messages | Update Error, Contact Error, Ribbon Break / Not Found Error, Remaining Ribbon Quantity, Number of Printed Templates, Number of Prints per Minute |
| Connection Types | Relay (NPN, PNP) - Photocell (NPN, PNP) |
| Communications | RS-232, Ethernet, USB |
| Ribbon Save Modes | Vertical & Horizontal Ribbon Save Modes |
| Advanced Control | 4.3" Touch Screen Control, Template Changing while Running, Print Position Adjustment, Contrast, Print Delay, Template-Specific Adjustment, Internal Contact Signal, Multi-print Contact Signal, Template Shifting, Template Rotation |
| Operator Interface | 4.3" 272x480 Pixels Resolution, Full-color display, Password protection on menus, Multi-language(18) support |
| Weight (Printer) | 5,6 Kg. |
| Dimensions | 175mm H x 190mm W x 197mm D |
- Intermittent mode operation — no air requirement, magnetic drive
- Robust mechanical design requires no maintenance
- 7" touch panel colour control screen
- 300 dpi (12 dots/mm) print resolution — horizontal and vertical
- 1,000 metre ribbon capacity
- 90°, 180° and 270° template rotation
- 5,000 template storage capacity in control screen memory
| Print Area | 32mm x 76mm |
|---|---|
| Print Speed | 50 - 500 mm/sec |
| Production | 330 print/min |
| Ribbon Widths & Length | 22mm, 35mm (0,9" - 1,4") & 1.000 meters (1.093 yards) loaded ribbon |
| Power Supply | 100-240V 50-60 Hz |
| Air Supply (Bar) | Min. 1 bar - Max. 5 bar |
| Input/Outputs | Print Signal/Fault Signal, Busy Signal |
| Output Messages | Update Error, Contact Error, Ribbon Break / Not Found Error, Remaining Ribbon Quantity, Number of Printed Templates, Number of Prints per Minute |
| Connection Types | Relay (NPN, PNP) - Photocell (NPN, PNP) |
| Communications | RS-232, Ethernet, USB |
| Ribbon Save Modes | Vertical & Horizontal Ribbon Save Modes |
| Advanced Control | 7" Touch Screen Control, Template Changing while Running, Print Position Adjustment, Contrast, Print Delay, Template-Specific Adjustment, Internal Contact Signal, Multi-print Contact Signal, Template Shifting, Template Rotation |
| Operator Interface | 7" 800x480 Pixels Resolution, Full-color display, Password protection on menus, Multi-language(18) support |
| Weight (Printer) | 9,4 Kg. |
| Dimensions | 180mm H x 265mm W x 237mm D |
- Continuous mode operation — ideal for high-speed form-fill-seal and wrapping lines
- 7" touch panel colour control screen
- 300 dpi (12 dots/mm) print resolution — horizontal and vertical
- 1,000 metre ribbon capacity
- 90°, 180° and 270° template rotation
- 5,000 template storage capacity in control screen memory
| Print Area | 53mm x 75mm |
|---|---|
| Print Speed | 50 - 500 mm/sec |
| Production | 330 prints/min |
| Ribbon Widths & Length | 35mm, 55mm (1,4" - 2,2") & 1.000 meters (1.093 yards) loaded ribbon |
| Power Supply | 100-240V 50-60 Hz |
| Air Supply (Bar) | Min. 1 bar - Max. 5 bar |
| Input/Outputs | Print Signal / Fault Signal, Busy Signal |
| Output Messages | Update Error, Contact Error, Ribbon Break / Not Found Error, Remaining Ribbon Quantity, Number of Printed Templates, Number of Prints per Minute |
| Connection Types | Relay (NPN, PNP) - Photocell (NPN, PNP) |
| Communications | RS-232, Ethernet, USB |
| Ribbon Save Modes | Vertical & Horizontal Ribbon Save Modes |
| Advanced Control | 7" Touch Screen Control, Template Changing while Running, Print Position Adjustment, Contrast, Print Delay, Template-Specific Adjustment, Internal Contact Signal, Multi-print Contact Signal, Template Shifting, Template Roration |
| Operator Interface | 7" 800x480 Pixels Resolution, Full-color display, Password protection on menus, Multi-language(18) support |
| Weight (Printer) | 11 Kg. |
| Dimensions | 180mm H x 248mm W x 265mm D |
- Intermittent mode operation — no air requirement, magnetic drive
- Robust mechanical design requires no maintenance
- 7" touch panel colour control screen
- 300 dpi (12 dots/mm) print resolution — horizontal and vertical
- 1,000 metre ribbon capacity
- 90°, 180° and 270° template rotation
- 5,000 template storage capacity in control screen memory
- Continuous mode operation — ideal for high-speed form-fill-seal and wrapping lines
- 7" touch panel colour control screen
- 300 dpi (12 dots/mm) print resolution — horizontal and vertical
- 1,000 metre ribbon capacity
- 90°, 180° and 270° template rotation
- 5,000 template storage capacity in control screen memory
| Print Area | 107mm x 76mm |
|---|---|
| Print Speed | 50 - 400 mm/sec |
| Production | Max. 320 prints/min |
| Ribbon Widths & Length | 110mm (4,28") & 1.000 meters (yards) loaded ribbon |
| Power Supply | 100-240V 50-60 Hz |
| Air Supply (Bar) | Min. 1 bar - Max. 4 bar |
| Input/Outputs | Print Signal / Fault Signal, Busy Signal |
| Output Messages | Update Error, Contact Error, Ribbon Break / Not Found Error, Remaining Ribbon Quantity, Number of Printed Templates, Number of Prints per Minute |
| Connection Types | Relay (NPN, PNP) – Photocell (NPN, PNP) |
| Communications | RS-232, Ethernet, USB |
| Ribbon Save Modes | Vertical & Horizontal Ribbon Save Modes |
| Advanced Control | 7” Touch Screen Control, Template Changing while Running, Print Position Adjustment, Contrast, Print Delay, Template-Specific Adjustment, Internal Contact Signal, Multi-print Contact Signal, Template Shifting, Template Rotation |
| Operator Interface | 7” 800x480 Pixels Resolution, Full-color display, Password protection on menus, Multi-language(20) support |
| Weight (Printer) | 11,6 Kg. |
| Dimensions | 180mm H x 265mm W x 303mm D |
- Intermittent mode operation — no air requirement, magnetic drive
- Robust mechanical design requires no maintenance
- 7" touch panel colour control screen
- 300 dpi (12 dots/mm) print resolution — horizontal and vertical
- 1,000 metre ribbon capacity
- 90°, 180° and 270° template rotation
- 5,000 template storage capacity in control screen memory
| Print Area | 107 mm x 125 mm (Standard), 107 mm x 250 mm (Optional 1), 107 mm x 500 mm (Optional 2) |
|---|---|
| Print Speed | 10 - 600 mm/sec |
| Production | Max. 300 prints/min |
| Ribbon Widths & Length | 110 mm (4,28”) & 1.000 meters (yards) loaded ribbon |
| Power Supply | 100-240V 50-60 Hz |
| Air Supply (Bar) | Min. 1 bar – Max. 4 bar |
| Input/Outputs | Print Signal/Fault Signal, Busy Signal |
| Output Messages | Missing Print Error, Encoder Error, Update Error, Contact Error, Ribbon Break / Not Found Error, Remaining Ribbon Quantity, Number of Printed Templates, Number of Prints per Minute |
| Connection Types | Relay(NPN, PNP) – Photocell(NPN, PNP) |
| Communications | RS-232, Ethernet, USB |
| Ribbon Save Modes | Vertical Ribbon Save Mode |
| Advanced Control | 7” Touch Screen Control, Template Changing while Running, Contrast, Print Delay, Template-Specific Adjustment, Internal Contact Signal, Multi-print Contact Signal, Template Shifting, Template Rotation |
| Operator Interface | 7” 800x480 Pixels Resolution, Full-color display, Password protection on menus, Multi-language(20) support |
| Weight (Printer) | 11,1 Kg. |
| Dimensions | 180mm H x 265mm W x 303mm D |
- Intermittent mode operation — no air requirement, magnetic drive
- Robust mechanical design requires no maintenance
- 7" touch panel colour control screen
- 300 dpi (12 dots/mm) print resolution — horizontal and vertical
- 600 metre ribbon capacity
- 90°, 180° and 270° template rotation
- 5,000 template storage capacity in control screen memory
| Print Area | 128 mm x 125 mm |
|---|---|
| Print Speed | 50 - 300 mm/sec |
| Production | Max. 280 prints/min |
| Ribbon Widths & Length | 130 mm (5,11”) & 600 meters (656yards) loaded ribbon |
| Power Supply | 100-240V 50-60 Hz |
| Air Supply (Bar) | Min. 1 bar – Max. 4 bar |
| Input/Outputs | Print Signal/Fault Signal, Busy Signal |
| Output Messages | Update Error, Contact Error, Ribbon Break / Not Found Error, Remaining Ribbon Quantity, Number of Printed Templates, Number of Prints per Minute |
| Connection Types | Relay(NPN, PNP) – Photocell(NPN, PNP) |
| Communications | RS-232, Ethernet, USB |
| Ribbon Save Modes | Vertical & Horizontal Ribbon Save Modes |
| Advanced Control | 7” Touch Screen Control, Template Changing while Running, Print Position Adjustment, Contrast, Print Delay, Template-Specific Adjustment, Internal Contact Signal, Multi-print Contact Signal, Template Shifting, Template Rotation |
| Operator Interface | 7” 800x480 Pixels Resolution, Full-color display, Password protection on menus, Multi-language(20) support |
| Weight (Printer) | 13,2 Kg. |
| Dimensions | 180mm H x 265mm W x 323mm D |
- Continuous mode operation — ideal for high-speed form-fill-seal and wrapping lines
- 7" touch panel colour control screen
- 300 dpi (12 dots/mm) print resolution — horizontal and vertical
- 600 metre ribbon capacity
- 90°, 180° and 270° template rotation
- 5,000 template storage capacity in control screen memory
| Print Area | 128 mm x 200 mm (Standard), 128 mm x 400 mm (Optional) |
|---|---|
| Print Speed | 10 - 400 mm/sec |
| Production | Max. 400 prints/min |
| Ribbon Widths & Length | 130 mm (5,11”) & 600 meters (656yards) loaded ribbon |
| Power Supply | 100-240V 50-60 Hz |
| Air Supply (Bar) | Min. 1 bar – Max. 4 bar |
| Input/Outputs | Print Signal/Fault Signal, Busy Signal |
| Output Messages | Missing Print Error, Encoder Error, Update Error, Contact Error, Ribbon Break / Not Found Error, Remaining Ribbon Quantity, Number of Printed Templates, Number of Prints per Minute |
| Connection Types | Relay(NPN, PNP) – Photocell(NPN, PNP) |
| Communications | RS-232, Ethernet, USB |
| Ribbon Save Modes | Vertical Ribbon Save Mode |
| Advanced Control | 7” Touch Screen Control, Template Changing while Running, Contrast, Print Delay, Template-Specific Adjustment, Internal Contact Signal, Multi-print Contact Signal, Template Shifting, Template Rotation |
| Operator Interface | 7” 800x480 Pixels Resolution, Full-color display, Password protection on menus, Multi-language(20) support |
| Weight (Printer) | 12,7 Kg. |
| Dimensions | 180mm H x 265mm W x 323mm D |
